Application conditions:

① any material with the amount of floating can be used

② in-mold tapping machine and the material does not have the same vertical movement

Tapping direction:

① up ② down ③ level

Application conditions:

① any material with the amount of floating can be used

② in-mold tapping machine and the material does not have the same vertical movement

Tapping direction:

① up ② down ③ level

Application conditions:

① material with a large amount of floating use

② In-mold tapping machine and tape at the same time vertical movement

Tapping direction:

① up ② down ③ level

Application conditions:

(1) When the material is released, the material is used

② in-mold tapping machine and the material does not have the same vertical movement

Tapping direction:

① down ② level

Application Conditions:

① Second element, three yuan manipulator feeding

② Single station independent movement tapping

③ Material with a floating height of more than 50MM

Tapping Direction:

① Up ② Down ③ Level

Chip free processing: Through the plastic deformation of the cold extrusion workpiece to complete, especially in the blind hole processing there is no chip removal problem, the parts will not crush and the tap is not easy to break.

High thread strength: The extrusion tap will not destroy the tissue fiber of the processed material, so the strength of the extruded thread is higher than that of the thread processed by the cutting tap.

High thread pass rate: Because it is chip free processing, the thread accuracy and thread profile consistency produced by processing are better than cutting taps; The cutting tap is completed by cutting, in the cutting process, the presence of scrap will more or less affect the quality of the thread.

Good tap strength: Because the extrusion tap has no chip groove, its own strength is much better than the cutting tap.

Long service life: Because the extrusion tap does not occur cutting edge passivation, falling edge and other problems, under normal circumstances, its service life is 3 to 20 times that of the cutting tap.

High production efficiency: Because of the longer service life and faster processing speed, the use of extrusion taps can reduce the time of changing taps and standby, thereby improving production efficiency.

No transition tooth thread: through its own to guide the processing, more suitable for thread processing, but also make no transition tooth processing possible.
